New Spectrum Analyzer Series

Nov. 22, 2017

Key Feature

1 to 100th harmonic and 99th inter-harmonic display

Sample rate can reach to 200kS/s

GPS/Beidou time synchronization

WIFI, LAN and USB Host communication

Input *Note: measured on Reference Voltage Input A/L1.

Voltage Input
Input Channels	4 (3 phase + neutral) DC coupling
Max continuous input voltage	(AC+DC)1000Vrms
Accuracy	±0.1% of nominal voltage
Max pulse peak voltage	6kV
Input impedance	4MΩ
Current Input
Input Channels	4 (3 phase + neutral) DC coupling
Type	Clamp Current Sensor, with mV output
Input range	0~6000A
Input impedance	100kΩ
Arms（AC） 10mV/A 1mV/A 65mV/1000A	0~100A 1~1000A 15~6000A
Sampling
Resolution	8 channels 16 bits ADC, sample synchronously
Sampling rate	Max 200kS/s

Measurement

	Measurement range	Resolution	Accuracy
Frequency
50Hz	42.50~57.50 Hz	0.001Hz	±0.01Hz
60Hz	51.00~69.00 Hz	0.001Hz	±0.01Hz
400Hz	385-414 Hz	0.01Hz	±0.1Hz
Harmonic
Harmonic number Interharmonic Harmonic voltage Harmonic current THD DC relative Frequency Phase	1~100 1~99 0.0~100.0% 0.0~100.0% 0.0~100.0% 0.0~100.0% 0~6000Hz -360°~ 0°	0.1% 0.1% 0.1% 0.1% 1Hz 1°	±0.1%±n×0.1% ±0.1%±n×0.1% ±2.5% ±0.2% 1Hz ±n×1.5°

General Characteristics
