Suin RF Signal Generators include several series, which have wide frequency ranges from 9 kHz up to 12 GHz, excellent output level range and ultralow phase noise, together with rich modulation functions. They can provide reliable tech-support to complex signal testing in the applications such as electronic circuit and devices testing.LABView software makes the remote controlling easy and convenient.
| Series | Frequency Range | Frequency Resolution | Level Range | Level Accuracy(Typ.) | Phase Noise(Typ.) | Modulation |
New
|
9 kHz~6.5 GHz | 0.01 Hz | -130 ~+20 dBm | ≤0.5 dB | <-110 dBc/Hz@20 kHz | AM, FM, PM, φM |
New
|
9 kHz~3.6 GHz | 0.01 Hz | -110 ~+20 dBm | ≤0.5 dB | <-105 dBc/Hz@20 kHz | AM, FM, PM, φM |
|
2 GHz~12 GHz | 1 Hz | -20 ~+15 dBm | ±1.5 dBm of setting | -105 dBc/Hz@100 kHz | Pulse Mod |
|
1 μHz~1.5 GHz | 1 μHz | -127 ~+13 dBm | setting ±1dBm | AM, FM, FSK, PSK | |
|
25 MHz~3 GHz | 3 Hz | -120 ~ +13 dBm | -90~115 dBc Offset 20 kHz | Pulse Mod |
