Universal frequency counters based on digital circuit technologies, can complete high accuracy measurement, such as frequency, period, time interval, statistics, etc. Suin frequency counters can measure three channels, 200 MHz frequency in CH1 and CH2, max 40 GHz in CH3 with high frequency channel options. Users can select suitable models according to its measuring resolution and time resolution.
| Series | CH | Frequency Range | Time Resolution | Time Interval | Statistics Calculation | Graphic Display | Measurement Resolution |
New
|
3 | 200 MHz(40 GHz option) | 25 ps | 1 ns~10000 s | Multi-average, Max, Min, PPM, SD, Allan Variance | Trendgram, Histogram | 11 digits/s |
|
3 | 200 MHz(40 GHz option) | 25 ps | 1 ns~10000 s | Multi-average, Max, Min, PPM, SD, Allan Variance | 11 digits/s | |
|
1 | 200 MHz(40 GHz option) | Multi-average, Max, Min, PPM, SD, Allan Variance | 10 digits/s |
