Programmable DC Power Supplies

SK13530 programmable power supply

SK13530 programmable power supply is a new generation of programmable DC power supplies. It protects itself by warning and cutting off output once fun controlling module gets fault, transistor over-heating, and internal bus gets fault. It is of programmable CV/ CC adjustable step.

    Brief Introduction

    SK13530 programmable power supply is a new generation of programmable DC power supplies. It protects itself by warning and cutting off output once fun controlling module gets fault, transistor over-heating, and internal bus gets fault. It is of programmable CV/ CC adjustable step. The two working states, CV and CC, can be switched varying with the load. Meantime, the external voltage sampling terminal is supplied to output stable voltage for user load within the range of wire voltage drop.


    SK13530 programmable power supplies are widely applied in national defense, institution, university, laboratory and factory, especially in the areas of computer measuring and automatic control system as DC power supply.


    Features

    All digital controlled, output 1mV/1mA step

    High stability, Low drift

    LED display the voltage/current and working status visually

    Intelligent temperature controlled fun with low noise

    Storage and recall function

    OVP (Over Voltage Protection) function

    Keypad locked function to avoid the misoperation

    Standard RS232 interface, optional USB


    SPECIFICATIONS


    Model

    SK11204

    SK16008

    SK13515

    SK12025

    Output Range

    120V/4A

    60V/8A

    35V/15A

    20V/25A

    Output Power

    500W

    Resolution

    1mV/1mA

    Source Effect

    CV

    ≤1×10-5+1mV

    CC

    ≤1×10-5+3mA

    Load Effect

    CV

    ≤1×10-4+3mV( Sense On)


    ≤1×10-4+30mV( Sense Off)

    CC

    ≤1×10-4+3mA

    Period and Random Deviation  (PARD)

    CV

    ≤1mV

    CC

    ≤6mA

    Accuracy

    Voltage

    ≤±(0.05%+10mV)

    Current

    ≤±(0.2%+50mA)

    OVP

    ≤±(0.5%+0.5V)

    General Characteristics

    Power

    AC220V(1±10%)V,50(1±5%)Hz

    Interface

    RS-232 (standard) USB (option)

    Dimension & Weight

    225×153×650 mm, Approx 25kg



    Model

    SK11206

    SK16012

    SK13520

    SK12035

    Output Range

    120V/6A

    60V/12A

    35V/20A

    20V/35A

    Output Power

    750W

    Resolution

    1mV/1mA

    Source Effect

    CV

    ≤1×10-5+1mV

    CC

    ≤1×10-5+3mA

    Load Effect

    CV

    ≤1×10-4+3mV( Sense On)


    ≤1×10-4+30mV( Sense Off)

    CC

    ≤1×10-4+3mA

    Period and Random Deviation  (PARD)

    CV

    ≤1mV

    CC

    ≤6mA

    Accuracy

    Voltage

    ≤±(0.05%+10mV)

    Current

    ≤±(0.2%+50mA)

    OVP

    ≤±(0.5%+0.5V)

    General Characteristics

    Power

    AC220V(1±10%)V,50(1±5%)Hz

    Interface

    RS-232 (standard)  USB (option)

    Dimension & Weight

    325×153×650 mm, Approx 30kg


    Model

    SK11208

    SK16016

    SK13530

    SK12050

    Output Range

    120V/8A

    60V/16A

    35V/30A

    20V/50A

    Output Power

    1000W

    Resolution

    1mV/1mA

    Source Effect

    CV

    ≤1×10-5+1mV

    CC

    ≤1×10-5+3mA

    Load Effect

    CV

    ≤1×10-4+3mV( Sense On)


    ≤1×10-4+30mV( Sense Off)

    CC

    ≤1×10-4+3mA

    Period and Random Deviation  (PARD)

    CV

    ≤1mV

    CC

    ≤20mA(applied to SK13530K)

    Accuracy

    Voltage

    ≤±(0.1%+10mV)(applied to SK13530K)

    Current

    ≤±(0.2%+50mA)(applied to SK13530K)

    OVP

    ≤±(0.5%+0.8V)(applied to SK13530K)

    General Characteristics

    Power

    AC220~230(198~242)V,50(47~63)Hz(applied to SK13530K)

    Interface

    RS-232 (standard)  USB (option)

    Dimension & Weight

    425×150×665 mm, 34kg

    325×150×450 mm, 13kg(applied to SK13530K)

    Standard Accessories

    Power Cord

    Power Cord

    1

    RS232 Cable

    RS232 Cable

    1

    CD(Software+ User's Guide)

    CD

    1

  • Detail
  • Software
  • Accessory
Related Products
Digital Multimeter SA5052 Series Digital Multimeter SA5052 Series
SA1000 Frequency Characteristic Analyzer SA1000 Frequency Characteristic Analyzer
Power Quality Analyzer SA2100 Power Quality Analyzer SA2100
