new products will be listed--SA9275 Spectrum Analyzer

Nov 23, 2017

Key Feature

*All-digital IF technology

*Frequency range from 9kHz to 7.5GHz

*-160dBm Display Average Noise Level (Tpy.)

*RBW(-3dB): 10Hz~1MHz, step 1-3-10

*< -100 dBc/Hz @10 kHz Offset Phase Noise

*Total Amplitude Accuracy < 0.8 dB

*Advanced Measurement included channel power, adjacent channel power, N-dB bandwidth, occupied bandwidth

*7 inch TFT LCD (800*480) display

*Standard interface of USB Device & Host, LAN and VGA.

*Preamplifier and EMI filter are standardly configured.
